Hypoglycaemic activity of Smilax canellifolia Mill. rhizomes: a bioassay-guided isolation and identification of synergistic compounds

Clinical Phytoscience volume 7, Article number: 89 (2021) Cite this article

Abstract

Background

Smilax canellifolia Mill. is a native shrub used in commercial root tonics as an aphrodisiac, stimulant, and pain reliever. Traditional medicine incorporates the rhizomes of S. canellifolia for the treatment of anaemia, rheumatoid arthritis, and diabetes in Jamaica and its diaspora. In particular, the use of this plant in the management of diabetes has yet to receive any scientific evaluation. In this study, the hexane crude extract of S. canellifolia rhizomes (SCH) was investigated to determine its hypoglycaemic activity in normal Sprague-Dawley rats and to identify the compounds contributing to this activity.

Methods

The hypoglycaemic compounds were isolated using bioactivity-guided purification which involved hypoglycaemic screening using an Oral Glucose Tolerance Test (via intravenous administration of SCH and its fractions). Purification was performed using column chromatography, and the bioactive fractions were elucidated using spectroscopic techniques (IR; GC-MS; 1H NMR and 13C NMR).

Results

Administration of SCH at 50 mg/kg body weight (BW) to normal S-D rats produced a reduced glycaemic response, notably from the 90 to the 150-min intervals when compared with the control, dimethyl sulfoxide (p < 0.05). Purification of this extract yielded four main fractions, SCH1 – SCH4, of which SCH3 and SCH4 displayed significant hypoglycaemia. Further purification of both SCH3 and SCH4 led to the isolation of sub-fractions SCH3.6 and SCH4.2, respectively. Using spectroscopic techniques stigmasterol (1) and β-sitosterol (2) from SCH3.6; and the fatty acids palmitic acid (3), oleic acid (4), and stearic acid (5) from SCH4.2 were identified as the major compounds with significant hypoglycaemic activities comparable to that of glibenclamide.

Conclusion

This study demonstrates that the rhizomes of Smilax canellifolia contain several bioactive constituents that are responsible for its hypoglycaemic activity and may be beneficial in the management of hyperglycaemia and complications associated with diabetes.

Background

It has been established that traditional and complementary medicine has had an intensified resurgence during the past decade. This has been due to an increase in the accessibility and acceptability of nutraceuticals, as well as a renewed focus on self-healing and preventative therapy [1]. The cost and availability of conventional drugs used to treat diabetes, and the belief in reduced toxicity from plant medicines have also stressed the demand for herbal or natural remedies [2]. Continuous research has therefore been encouraged to validate and integrate herbal alternatives into healthcare systems especially in countries with East Asian and African medicinal influences [1, 3,4,5,6].

Smilax canellifolia Mill. (S. canellifolia) is a member of the Liliaceae family and the Smilax genus, comprising over 350 species. In Jamaica, S. canellifolia is known as Smilax balbisiana, which has recently been identified as the illegitimate synonym [7]. This native shrub is found widely cultivated in the woodlands of the Cockpit Country, Jamaica. The rhizomes of S. canellifolia, commonly known as Chainy Root, are used as a staple ingredient in Jamaica’s traditional “Roots” tonics [8, 9]. S. canellifolia is a climbing shrub, with brambled and thorny tendril-climbing vines that can grow up to 50 m long. These woody vines sprout from a thick basal rhizome that is deep red/brown in colour. The basal leaves are broad and ovate, while the terminal leaflets are lanceolate or elliptical; these leaves are often paired tendrils emerging from the base of the petiole. Its flowers are small and green, while the berries range from reddish-purple to black and are 5 – 7 mm in diameter [9, 10]. The rhizomes are believed to be an aphrodisiac used to improve impotence and increase energy. Chainy Root is also used in folklore medicine to treat anaemia, analgesia, rheumatoid arthritis, and diabetes [11, 12]. Other Smilax species have been found to display considerable ethnopharmacological activities including antioxidant, antidiabetic, hypotensive and anti-inflammatory effects [13,14,15,16,17,18]. However, along with the variation in species, the plant parts and solvents used to obtain the extracts that have been investigated, the extract used to produce significant hypoglycaemic effects were different from those used in our research. These reports also failed to explicitly identify the active naturally occurring compounds responsible for the hypoglycaemic or antidiabetic effects observed [14, 16, 18]. The crude extracts of S. canellifolia rhizomes have previously been reported to possess significant hypoglycaemic potential in animals [19, 20]. Considering these findings, this investigation focused on isolating and identifying the bioactive compounds that contributed to the hypoglycaemic activity of S. canellifolia rhizomes in Sprague-Dawley rats. It is anticipated that these findings will expand the potential use of S. canellifolia rhizomes for the management of diabetes and possibly, its inherent complications.

Material and methods

Chemicals and reagents

All reference standards were purchased from Sigma-Aldrich (St. Louis, USA). Dimethyl sulfoxide (DMSO) was purchased from Sigma-Aldrich (St. Louis, USA). All other solvents were purchased from Pharmco-Aaper (Ontario, Canada) and were of analytical grade.

Plant material

S. canellifolia rhizomes were collected in March 2016 from Accompong, St. Elizabeth, Jamaica. A sample of the rhizome was authenticated at the University of the West Indies (UWI), Mona Herbarium with an assigned Voucher number, 3633.

Screening for Hypoglycaemic activity

Animals

Normoglycaemic Sprague-Dawley (S-D) rats (150–200 g; n = 5 per group) of mixed sexes were obtained from the UWI, Basic Medical Sciences Animal House (Mona, Jamaica). Animals were housed in stainless steel cages inside a ventilated room with an alternate 12 h dark/light period. The animals had free access to water and a standard laboratory diet (LabDiet 500, MO, USA). All animal experiments were approved by the UWI, Mona Campus Research Ethics Committee (Reference No. AN, 8, 14/15).

Experimental design; Oral glucose tolerance test (OGTT)

The OGTT was performed using a modified method [21]. The rats were weighed then fasted overnight (approximately 12 h) before experimentation, and water was provided ad libitum.

An incision was made at the tip of the animal’s tail to obtain an initial fasting blood glucose reading. The pre-weighed crude or purified hexane extract (10–50 mg/kg body weight/BWFootnote 1) was dissolved in the vehicle, DMSO (0.3 mL), and administered intravenously (i.v.). Afterwards, blood glucose readings were measured at 30 and 60-min post-administration. Subsequently, a glucose load of 1.75 g/kg BW was administered by oral gavage. Blood glucose readings were taken at 30-min intervals for a further two and a half (2.5) hours using the ACCU-Chek Active Blood Glucose Monitoring System.

Extraction and purification of hexane crude extract (SCH)

The shade-dried (~ 28 °C) and powdered rhizomes (7.5 kg) were extracted with hexane. The plant material was initially saturated with hexane (2 L) at room temperature for two separate eight (8) hour periods and one twenty-four (24) hour period. Fresh solvent (1 L) was added for each treatment period, and the filtrates were collected and concentrated using rotary evaporation. The hexane crude extract was weighed (16.5 g) and the recovery percentage (0.22%) was determined.

The hexane crude extract from the rhizomes of S. canellifolia (SCH) was obtained as a gold oily residue and displayed significant hypoglycaemic activity during an OGTT. TLC analysis showed that several unresolved compounds were present. The extract (SCH, 16.24 g) was subjected to column chromatography (30 × 6.5 cm; 200 – 425 mesh) and eluted with gradient Hex – EtOAc (90:10 to 0:100, v/v) solvent system, collecting 150 mL volumes. The eluted fractions were later pooled based on the similarity of their Thin-layer chromatography (TLC) profiles to afford four main fractions designated SCH1 (0.24 g), SCH2 (7.52 g), SCH3 (3.17 g) and SCH4 (1.73 g). The spots were visualized under white light, UV light, and after spraying with 10% sulfuric acid reagent.

The main fractions were subjected to hypoglycaemic screening (OGTT), where SCH3 and SCH4 displayed significant hypoglycaemic activity and were subjected to further purification.

SCH3 (2.31 g) was separated using silica gel column (140 g) and eluted with a petroleum ether – EtOAc (90:10 to 10:90, v/v) eluent, collecting 40 mL volumes to obtain 38 fractions in total. TLC comparisons afforded nine sub-fractions: SCH3.1 (0.02 g), SCH3.2 (0.48 g), SCH3.3 (0.78 g), SCH3.4 (0.26 g), SCH3.5 (0.32 g), SCH3.6 (0.18 g), SCH3.7 (0.20 g), SCH3.8 (0.03 g) and SCH3.9 (0.04 g). Sub-fractions SCH 3.1, SCH3.3, SCH3.6 and SCH3.8 were subjected to biological assay (bioassay) screening using  an OGTT.

Fraction SCH4 (0.63 g) was subjected to further purification using silica gel (63 g) and eluted with gradient mixtures of Hex – EtOAc (90:10 to 0:100, v/v). Elution was monitored by TLC and profile comparison produced six sub-fractions: SCH4.1 (0.24 g), SCH4.2 (0.13 g), SCH4.3 (0.02 g), SCH4.4 (0.03 g), SCH4.5 (0.04 g) and SCH4.6 (0.17 g). Sub-fractions SCH4.1 and SCH4.2 were selected due to their recovery percentage and screened for hypoglycaemic activity.

After the bioassay (OGTT), sub-fractions SCH3.6 and SCH4.2 demonstrated significant hypoglycaemic activity. They were subjected to spectroscopic (IR, 13 C NMR, and 1H NMR) and spectrometric (GC-MS) analyses to elucidate their bioactive constituents.

Spectroscopic analysis and structural identification of SCH sub-fractions

Column chromatography was carried out using silica gel 60 Å (200 – 425 mesh; Sigma-Aldrich, St. Louis, USA). TLC was carried out on normal phase silica gel 60 F254 on pre-coated plastic plates (Sigma-Aldrich, St. Louis, USA), using 5% sulfuric acid spray after heating or ultraviolet (UV) light (254 nm and 365 nm) for visualization.

Infrared (IR) spectra were obtained using the Nicolet iS10 FTIR spectrometer with ATR accessories. 13C NMR and 1H NMR spectra were recorded on a Bruker DRX-500 MHz and DRX-200 MHz spectrometer (for 1D and 2D respectively) in deuterated chloroform. Chemical shifts (δ) were expressed in parts per million (ppm) with reference to tetramethylsilane (TMS).

Gas Chromatography-Mass Spectroscopy analyses were performed using a DB-1701 GC capillary column (30 mm, 0.25 mm i.d., 0.25 μm film thickness) on an Agilent 6890 N gas chromatograph (GC) equipped with an Aligent 5973 N Mass Selective Detector, using helium carrier gas at a flow rate of 1.2 mL min− 1. A ramped temperature program was employed for the oven, starting at 80 °C at a rate of 2 °C min− 1 for 10 min. The samples were reconstituted in chloroform (1 μL) and injected in splitless mode at 250 °C. Mass spectra operations were performed in electron impact (EI+) mode at 70 eV. The chromatogram was acquired in total ion current (TIC), and the data was given in m/z values. Derivatization was done using Bis-(trimethylsilyl)-trifluoroacetamide (BSTFA). All preliminary identifications were obtained using the NIST/EPA/NIH Mass Spectral Database (version NBS75K.L). The compounds identified were then confirmed by comparison of their retention indices and mass spectra with those of the authenticated standards under the same conditions. The relative ratio of the compounds identified was computed from the GC area percentage and excluded correction factors. All chemical structures were constructed using ACD/ChemSketch software (ACD/Labs version 2019).

Statistical analysis

The results were presented as mean ± standard error of the mean (SEM). Statistical analysis was carried out using a statistical software (SPSS, Version 22, Chicago, IL, USA) to perform the Student’s t-test. Values were considered statistically significant at p < 0.05.

Results

Hypoglycaemic screening

The effect of Smilax canellifolia rhizomes hexane crude extract (SCH) and its semi-purified fractions on blood glucose (BG) concentration were evaluated using an Oral Glucose Tolerance Test (OGTT). It was evident that the control (DMSO; vehicle) produced a glucose tolerance curve demonstrative of a typical response to an oral glucose load. Its administration had a characteristic glycaemic peak at the 90-min interval, followed by a general decrease due to the action of insulin (Fig. 1a).

Fig. 1
figure 1

a Effect of Smilax canellifolia rhizomes hexane crude extract (SCH; 50 mg/kg BW) and sub-fractions (SCH1–SCH2; 25 mg/kg BW) on blood glucose concentration. Data expressed as mean ± SEM (n = 5); * represents p < 0.05 vs control. b. Effect of SCH (50 mg/kg BW) and sub-fractions (SCH3–SCH4; 25 mg/kg BW) on blood glucose concentration. Data are mean ± SEM (n = 5); * represents p < 0.05 vs control

Full size image

Intravenous administration of SCH, at 50 mg/kg BW was able to produce a significant reduction in BG levels throughout the OGTT when compared with the control, DMSO. Before the oral administration of glucose, a hypoglycaemic response was observed during the fasted state, that is, at the 30 and 60-min intervals (p < 0.05). This reduction persisted post-glucose administration from the 90-min interval (4.31 ± 0.34 mmol/L vs. 5.74 ± 0.14 mmol/L; p = 0.017) up to the 150-min interval (3.6 ± 0.53 mmol/L vs. 5.10 ± 0.30 mmol/L; p = 0.035) when compared with the control. Consequently, the semi-purified fractions of SCH (SCH1 – SCH4; 25 mg/kg BW) also displayed varying hypoglycaemic responses, when administered intravenously. SCH1 improved glucose tolerance at the 120-min interval when compared with the control (p < 0.05; Fig. 1a). However, it was evident that both SCH3 and SCH4 exerted the most notable hypoglycaemic effects (Fig. 1b). SCH3 was able to show a significant reduction in BG levels at the 90-min interval (4.30 ± 0.42 mmol/L vs. 5.74 ± 0.14 mmol/L; p = 0.036), and at the 120-min interval (4.46 ± 0.30 mmol/L vs. 5.49 ± 0.23 mmol/L; p = 0.026) when compared with the control (Fig. 1b). Similarly, SCH4 displayed hypoglycaemic activity from the 90-min interval (4.33 ± 0.52 mmol/L vs. 5.74 ± 0.14 mmol/L; p = 0.023) up to the 180-min interval (3.39 ± 0.45 mmol/L vs. 5.26 ± 0.32 mmol/L; p = 0.037). Further investigation into the hypoglycaemic potential displayed by SCH3 and SCH4 led to their purification, which afforded several sub-fractions, SCH3.1 – SCH3.9 and SCH4.1 – SCH4.6, respectively.

The screening of SCH3.1, SCH3.3, SCH3.6, and SCH3.8 (10 mg/kg BW via intravenous administration) obtained from SCH3 indicated that all except SCH3.6 had no significant effect on BG levels when compared with the control (p > 0.05; Fig. 2). Fasted state hypoglycaemia was observed following the administration of SCH3.6 at the 30-min (2.38 ± 0.54 mmol/L vs. 5.05 ± 0.28 mmol/L; p = 0.002) and 60-min (2.40 ± 0.50 mmol/L vs. 4.59 ± 0.21 mmol/L; p = 0.003) intervals when compared with the control. Remarkably, postprandial hypoglycaemia was observed which persisted throughout the experiment, up to the 210-min interval (1.96 ± 0.37 mmol/L vs. 4.98 ± 0.43 mmol/L; p = 0.001). A comparison of SCH3.6 with the commercial hypoglycaemic agent, glibenclamide (5 mg/kg BW), showed a similar hypoglycaemic response in the fasted and postprandial state, (p > 0.05; Fig. 2). When SCH3.1, SCH3.3 and SCH3.8 were compared with glibenclamide, all were significantly different (p < 0.05: Fig. 2).

Fig. 2
figure 2

Effect of sub-fractions (10 mg/kg BW) from SCH3 and glibenclamide (5 mg/kg BW) on blood glucose concentration. Data expressed as mean ± SEM (n = 5); * represents p < 0.05 vs control and # represent p < 0.05 vs glibenclamide

Full size image

SCH4.1 and SCH4.2 (10 mg/kg BW) obtained from SCH4 were screened and found to display hypoglycaemic activity (Fig. 3). When administered intravenously, SCH4.1 led to a transient lowering in the BG level at the 120-min interval (4.48 ± 0.36 mmol/L vs. 5.49 ± 0.23 mmol/L; p = 0.040) when compared with the control. However, SCH4.2 illustrated significant reduction in BG level at the 60-min interval (3.57 ± 0.27 mmol/L vs. 4.59 ± 0.21 mmol/L; p = 0.017); substantial improvement in postprandial glucose tolerance was also observed from the 90-min (4.74 ± 0.38 mmol/L vs 5.74 ± 0.14 mmol/L; p = 0.040) to the 150-min (3.89 ± 0.33 mmol/L vs. 5.10 ± 0.30 mmol/L; p = 0.025) interval when compared with the control. A comparison of SCH4.1 with glibenclamide highlighted that SCH4.1 had a comparable effect on the glycaemic response at the 120-min interval (p > 0.05; Fig. 3). SCH4.2 also had a comparable effect on the glycaemic response to that displayed by glibenclamide at the 60 and 90-min intervals (p > 0.05; Fig. 3).

Fig. 3
figure 3

Effect of sub-fractions (10 mg/kg BW) from SCH4 and glibenclamide (5 mg/kg BW) on blood glucose concentration. Data expressed as mean ± SEM (n = 5); * represents p < 0.05 vs control and # represent p < 0.05 vs glibenclamide

Full size image

Spectroscopic identification

Sub-fraction SCH3.6

SCH3.6 was isolated as white needle-shaped crystals (m.p. 133 – 136 °C) upon recrystallization in cold ethyl acetate. The IR absorption spectrum of SCH3.6 showed absorption peaks at 3361.86 cm-1 (OH stretching), 2950 cm-1, 2850 cm-1 (C-H stretching), 1379 cm-1, 1368 cm-1 (C-H stretching; geminal dimethyl), 1709 cm-1 (C=O stretching), 1464 cm-1 (C-H bending, methyl group), 971 cm- 1, 959 cm-1 (di-substituted trans C=C bending) and 1048 cm-1, 1022 cm-1. Other bands present at 882 cm- 1, 839 cm-1, and 780 cm-1 (tri-substituted C-H bending).

1H NMR data confirmed the steroidal nature of the compound(s) in SCH3.6 were due to the characteristic cluster of proton peaks in the 0.50 – 2.50 ppm region. The data showed the presence of two non-protonated carbons, two methines, nine methylenes, and six methyls. The methyl singlets were seen at δ = 0.68 (s, 3H) and δ = 1.03 (s, 3H) representing the angular methyl groups at C28and C29, respectively. Two geminal methyl groups were also observed at δ = 0.87 (d, 3H) and δ = 0.87 (d, 3H) for C26 and C27, respectively. At C19, the methyl was a doublet at δ = 0.94 (d, 3H), and a terminal methyl at C24 occurred at δ = 0.87 (t, 3H). SCH3.6 also showed protons at δ = 5.01 (m, 1H), δ = 5.15 (m, 1H), and δ = 5.37 (t, 1H) which suggested the presence of a trisubstituted olefinic bond and disubstituted olefinic bond. The trisubstituted proton signal correlated with a double bond system at C20/C21, while the latter proton signal corresponded to the double bond at C5/C6. The signal occurring at δ = 5.37 (tdd, 1H) corresponded to the H-3 of the oxymethine moiety of a sterol. The appearance of mirror shifts in the 13C NMR spectra (Table 1) alluded to the presence of two similar compounds and was consistent with the literature [22].

Table 1 13C NMR chemical shift values (ppm) of stigmasterol and β-sitosterol recorded in CDCl3
Full size table

GC-MS analysis indicated that SCH3.6 contained several components, however, two were present in greater proportions (See supplemental file, Fig. 1S). The mass spectrum of the peak A, (retention time [RT], 16.21 min) showed a weak molecular ion peak at m/z 484 which corresponded to the molecular formula C32H56OSi [M +], other peaks observed at m/z 469 [M+ − Me], 394 [M+ − C6H18], 379 [M+ − C7H21], 129, 83, 55. Peak B (RT, 17.01 min) had a molecular ion peak at m/z 486 [M+], which corresponded to the molecular formula C32H58OSi [M+]. Other ion peaks were observed at m/z 471 [M+ − Me], 396 [M+ − C6H18], 381 [M+ − C7H21], 129, 73, 57. Spectrometric analyses along with GC area percentage (%) identified peaks A and B as the trimethylsilyl (TMS) derivatives of stigmasterol (compound (1); 15.26%) and β-sitosterol (compound (2); 35.56%). These phytosterols were the major components of SCH3.6 (Fig. 4). The remaining components consisted of medium and short-chain fatty acids, primarily palmitic acid (8.55%) and oleic acid (3.5%). Reference standards for stigmasterol trimethylsilyl ether (RT, 16.10 min) and β-sitosterol trimethylsilyl ether (RT, 16.96 min) also produced identical MS fragment ions.

Fig. 4
figure 4

Structure of stigmasterol (1) and β-sitosterol (2)

Full size image

Sub-fraction SCH4.2

SCH4.2 (m.p. 63 – 68 °C) was isolated as an aggregate of off-white amorphous solid embedded in a colourless oil. IR absorption was observed at 2915 cm− 1 and 2849 cm− 1 (C-H stretching), 1706 cm− 1 (C=O stretching), 1464 cm− 1 (C-H bending; methylene), 1411 cm− 1 (O-H bending). The peaks were characteristic of fatty acids.

GC-MS analysis indicated that SCH4.2 contained several fatty acids (compounds 3 – 5), which accounted for greater than 75% of the total area percentage (See supplemental file, Fig. 2S). MS data of peak A (RT, 12.86 min) showed a weak molecular ion peak at m/z 328 which corresponded to the molecular formula C19H40OSi [M+], other peaks were observed at m/z 313 [M+ − Me], 285 [M+ − Pr], 145, 132, 129,117, 73. Peak B (RT, 13.72 min) with the molecular ion peak at m/z 354 [M+] corresponded to the molecular formula C18H34OSi [M+]. Other ion peaks were observed at m/z 339 [M+ − Me], 264 [M+ − C6H18], 145,129, 117, 73. Peak C (RT, 13.83 min) molecular ion peak at m/z 356 [M+] corresponded to the molecular formula C18H36OSi [M+]; other ion peaks were observed at m/z 341 [M+ − Me], 313 [M+ − Pr], 145, 132, 117, 73. MS data and GC area % identified peaks A, B and C as the TMS derivatives of hexadecanoic acid (42.11%) and (9Z)-octadec-9-enoic acid (31.84%) and octadecanoic acid (5.84%) which were the major components of SCH4.2 (Fig. 5). Reference standards for hexadecanoic acid, trimethylsilyl ester (palmitic acid, TMS derivative; RT, 12.93 min), (9Z)-octadec-9-enoic acid, trimethylsilyl ester (oleic acid, (Z)-, TMS derivative; RT, 13.86 min) and octadecanoic acid, trimethylsilyl ester (stearic acid, TMS derivative; RT, 13.94 min) also produced identical MS fragment ions.

Fig. 5
figure 5

Structure of hexadecanoic acid/palmitic acid (3), (9Z)-Octadec-9-enoic acid/oleic acid (4) and octadecanoic acid/stearic acid (5)

Full size image

Discussion

A survey that was conducted in Jamaica highlighted the popularity of self-medicating with traditional medicine for the treatment of common ailments and chronic diseases, including diabetes and hypertension [23]. The rhizomes of Smilax canellifolia, though commonly used as a general health tonic and aphrodisiac has been noted in folklore to be beneficial in the treatment of diabetes [8, 9]. Smilax species have made significant contributions as alternative interventions for the treatment of hyperglycaemia, hypertension, and oxidative stress, which are all associated with diabetes [13,14,15, 18, 24].

This study conducted hypoglycaemic screening on the hexane crude extract of S. canellifolia rhizomes in normoglycaemic rats, which highlighted that intravenous administration (50 mg/kg BW) produced significant hypoglycaemic responses (Fig. 1a). The reduced glycaemic peak observed at the 90-min interval indicated that the extract contained compounds that were able to enhance blood glucose clearance. In previous investigations, the hexane crude extract was found to exert the most potent hypoglycaemic effect from a group of three solvent extracts (hexane, ethyl acetate and methanol) that were screened. The prolonged hypoglycaemic effect displayed by the hexane crude extract (SCH) when compared with the other extracts was significant and therefore, it was consequently subjected to bioassay-guided purification [20, 25]. In contrast, other Smilax species such as S. aristolochiifolia and S. moranensis indicated that their polar solvent extracts (methanol or ethanol-water) produced the most potent hypoglycaemic effects [13, 26, 27]. These studies also focused on other parts of the plant (leaves and roots) and indicated that the bioactive compounds were possibly flavonoids, alkaloids, and polyphenols – some of which were absent in our hexane extract from S. canellifolia rhizomes, possibly due to the variation in polarity [25].

Further screening of the semi-purified fractions (25 mg/kg BW; intravenous administration) from SCH, illustrated that SCH3 and SCH4 were significant in their ability to lower the postprandial glycaemic responses during the OGTT (Figure 1b). Studies have found that therapeutics that target postprandial hyperglycaemia were beneficial in the initial treatment of diabetes as they reduce the formation of glycated-end products and oxidative stress [28, 29]. Therefore, natural products that can manage this glycaemic spike may have significant potential as alternative medicines used for diabetes.

Chromatography purification of SCH3 and SCH4 led to the isolation of phytosterols (SCH3.6) and fatty acids (SCH4.2), respectively as revealed by spectroscopy analyses. They were identified as the key naturally isolated compounds to which the hypoglycaemic activities were attributed. It has been noted that the various pharmacological activities displayed by Smilax species could, in part, be linked to the presence of phytosterols that enhanced the absorption and bioavailability of other phytochemicals and drugs [30].

Sub-fraction SCH3.6 (10 mg/kg BW; intravenous administration) displayed significant hypoglycaemia when compared with the control (Fig. 2). GC-MS analysis identified the main constituents of this sub-fraction as a mixture of stigmasterol and β-sitosterol, with several fatty acids making up the remaining minority (Fig. 4). Stigmasterol and β-sitosterol are sterols (steroid alcohols) found mainly in plants (phytosterols), with structural similarity to cholesterol [31]. These sterols differ from cholesterol with the addition of an ethyl group in their side chain, while the unsaturation at carbon 20–21 of stigmasterol distinguishes it from β-sitosterol. Phytosterols are utilized as precursors/ intermediate molecules in plant development and cell signaling [32]. Studies have highlighted that stigmasterol and β-sitosterol exhibit antidiabetic and hypoglycaemic effects in both diabetic and healthy animals respectively[33, 34]. They also have potential antioxidative, hepatoprotective, and anti-inflammatory effects [35]. In this study, the hypoglycaemic effect observed throughout the OGTT could be linked to the phytosterols’ stimulatory effects on insulin secretion [30, 36]. This hypoglycaemic effect may also be independent of BG concentration, as observed with the significant lowering in the animals’ fasted BG levels (Fig. 2). Jamaluddin et al. suggested that the hypoglycaemic effect of these phytosterols in Parkia speciosa was due to their synergistic action. When orally administered to diabetic rats, each individual phytosterol failed to cause significant hypoglycaemia [33]. In our study these naturally occurring phytosterols, when administered (intravenously) in combination, also produced significant BG concentration reduction in normoglycaemic S-D rats. The effect observed may have been due to the evasion of the first-pass metabolism, which could have contributed to the rapid onset of hypoglycaemia, as observed in the fasted state.

SCH4.2 was found to contain palmitic acid (PA), oleic acid (OA) and stearic acid (SA). Although these fatty acids (FAs) have been identified in Smilax species, their occurrence has never been reported as the components contributing to their hypoglycaemic activity [37]. Fatty acids are carboxylic acids with hydrophobic hydrocarbon chains that are categorized based on the absence (saturated FA) or presence and position of double bonds (unsaturated; cis and trans) along these chains. The length of these FA chains also determines their physiological use as high energy sources and cell membrane components [38]. PA and SA are bothsaturated fatty acids while OA is a monounsaturated fatty acid. A balanced ratio (saturated : unsaturated ) of these three fatty acids will ensure the homeostatic functioning of membrane phospholipids that are vital in regulating intracellular signaling and maintaining membrane structure and fluidity [38]. This balance also reduces the risks of cardiovascular diseases, hyperglycaemia and inflammatory events due to an accumulation of saturated FAs, especially PA [39]. Free fatty acids (FFAs) are known to increase insulin secretion at elevated glucose concentrations [40, 41]. While OA and PA can enhance insulin secretion at physiologically low BG levels, this effect is more apparent with monounsaturated FAs [42]. This insulin-independent effect may have accounted for the reduction observed in the fasted state (60-min interval; Fig. 3). Our findings indicated that the administration of SCH4.2, containing primarily PA, OA, and SA, was able to produce a significant reduction in the postprandial BG levels. The FAs were determined to occur at a ratio of 7:5:1 naturally, and their hypoglycaemic effect may have been in response to the synergistic action of the FFAs and their impact on insulin release [40]. Daley-Beckford et al. conducted a similar study using healthy normoglycaemic S-D rats [43]. They concluded that a mixture of PA and OA in the ratio of 2.3:1 from Eucalyptus camaldulensis was able to improve glucose tolerance (postprandial). The glycaemic control produced was associated with an increase in insulin secretion in the animals. Moreover, PA and OA were also found to contribute to the antidiabetic effect observed in Juniperus oxycedrus leaves [44]. Studies have indicated that the hypoglycaemic effect observed with the administration of these fatty acids could also be associated with their ability to trigger GLUT-4 translocation in rat skeletal muscles [45, 46]. This fatty acid-stimulated glucose uptake was linked to increased phosphorylation of signaling proteins, which are critical components in GLUT-4 translocalization [45,46,47]. These findings suggest that an increase in GLUT-4 mediated glucose uptake and insulin secretion could be the primary mechanism ofhypoglycaemiafor the fatty acids identified in this study [45].

Conclusion

This study has established that several compounds present in the hexane sub-fractions of Smilax canellifolia rhizomes had a synergistic hypoglycaemic effect. These compounds were identified as stigmasterol, β-sitosterol, and the fatty acids: palmitic acid, oleic acid, and stearic acid. It was evident that these naturally occurring compounds contributed to an improvement in postprandial glucose tolerance, which led to significant hypoglycaemic activity when administered to Sprague-Dawley rats. This is the first report on the purification, isolation and identification of the hypoglycaemic compounds from S. canellifolia rhizomes. Overall, the presence of these bioactive constituents in S. canellifolia rhizomes add credence to its use in folklore medicine. We, therefore, propose to further ascertain the antidiabetic and physiological effects of these constituents in a diabetic animal model. Smilax canellifolia rhizomes have the potential to be used as a phytopharmaceutical or nutraceutical in the management of diabetes.

Availability of data and materials

The authors declare that [the/all other] data supporting the findings of this study are available within the article [and its supplementary information files].

Notes

  1. The dosage required to observe the hypoglycaemic effect was lowered after each stage of the purification process from 50 mg/kg to 25 mg/kg then to 10 mg/kg body weight.

Abbreviations

BG:

Blood glucose

BSTFA:

Bis-(trimethylsilyl)-trifluoroacetamide

DMSO:

Dimethyl sulfoxide

FFAs:

Free fatty acids

FAs:

Fatty acids

OA:

Oleic acid

OGTT:

Oral Glucose Tolerance Test

PA:

Palmitic acid

RT:

Retention time

S. canellifolia :

Smilax canellifolia Mill.

SCH:

Smilax canellifolia rhizomes hexane crude extract

S-D:

Sprague-Dawley

SA:

Stearic acid

TMS:

Tetramethylsilane

UWI:

University of the West Indies

References

  1. Zhang Q. Global situation and WHO strategy on traditional medicine. Tradit Med Mod Med. 2018;01(01):11–3.

    Article  Google Scholar

  2. Bhagour K, Arya D, Gupta RS. A review: antihyperglycemic plant medicines in management of diabetes. Acupunct Relat Ther. 2016;4(4):7–16.

    Article  Google Scholar

  3. Addae-Mensah I, Fakorede F, Holtel A, Nwaka S. Traditional medicines as a mechanism for driving research innovation in Africa. Malar J. 2011;10(Suppl. 1):1–4.

    Google Scholar

  4. Živković J, Ilić M, Zdunić G, Jovanović-Lješković N, Menković N, Šavikin K. Traditional use of medicinal plants in Jablanica district (south-eastern Serbia): ethnobotanical survey and comparison with scientific data. Genet Resour Crop Evol. 2021;68(4):1655–74.

    Article  Google Scholar

  5. Cahyaningsih R, Magos Brehm J, Maxted N. Setting the priority medicinal plants for conservation in Indonesia. Genet Resour Crop Evol. 2021;68(5):2019–50.

    Article  Google Scholar

  6. Yuan H, Ma Q, Ye L, Piao G. The traditional medicine and modern medicine from natural products. Molecules. 2016;21(5):559.

  7. Vandebroek I, Picking D, Tretina J, West J, Grizzle M, Sweil D, et al. Root tonics and resilience: building strength, health, and heritage in Jamaica. Front Sustain Food Syst. 2021;5:42.

    Article  Google Scholar

  8. Mitchell SA. The Jamaican root tonics: a botanical reference. Focus Altern Complement Ther. 2011;16(4):271–80.

    Article  Google Scholar

  9. Mitchell SA, Ahmad MH. Morphology, horticulture and biotechnology of root tonic non-timber forest species of Jamaica including the endemic plant, Chainy Root (Smilax balbisiana). In: 1st International Symposium on Tropical Horticulture. Kingston, Jamaica; 2010. p. 42.

    Google Scholar

  10. Adams CD. Flowering plants of Jamaica. Mona: University of the West Indies; 1972.

    Google Scholar

  11. Bulgin-Graham A-M. Chaney Root Medicinal Herb | Jamaican Tonic - Medicinalherbs-4u.com [Internet]. [cited 2020 Aug 6]. Available from: https://www.medicinalherbs-4u.com/chaney-root.html

  12. Mitchell SA, Ahmad MH. A review of medicinal plant research at the University of the West Indies, Jamaica, 1948-2001. West Indian Med J. 2006;55(4):243–69.

    Article  CAS  PubMed  Google Scholar

  13. Amaro CAB, González-Cortazar M, Herrera-Ruiz M, Román-Ramos R, Aguilar-Santamaría L, Tortoriello J, et al. Hypoglycemic and hypotensive activity of a root extract of Smilax aristolochiifolia, standardized on N-trans-feruloyl-tyramine. Molecules. 2014;19(8):11366–84.

    Article  PubMed  PubMed Central  Google Scholar

  14. Andrade-Cetto A. Hypoglycemic effect of Smilax moranensis root on N5-STZ diabetic rats. Pharmacologyonline. 2011;1:111–5.

    Google Scholar

  15. Challinor VL, Parsons PG, Chap S, White EF, Blanchfield JT, Lehmann RP, et al. Steroidal saponins from the roots of Smilax sp.: structure and bioactivity. Steroids. 2012;77(5):504–11.

    Article  CAS  PubMed  Google Scholar

  16. Fukunaga T, Miura T, Furuta K, Kato A. Hypoglycemic effect of the rhizomes of Smilax glabra in normal and diabetic mice. Biol Pharm Bull. 1997;20(1):44–6.

    Article  CAS  PubMed  Google Scholar

  17. Lee SE, Ju EM, Kim JH. Free radical scavenging and antioxidant enzyme fortifying activities of extracts from Smilax China root. Exp Mol Med. 2001;33(4):263–8.

    Article  CAS  PubMed  Google Scholar

  18. Solomon Raju BG, Ganga Rao B, Manju Latha YB. Antidiabetic activity of Smilax China roots in alloxan-induced diabetic rats. Int J PharmTech Res. 2012;4(1):369–74.

    Google Scholar

  19. Peddie DA, Alexander-Lindo RL. The effect of Smilax balbisiana (Chainy Root) on blood glucose concentration and haemodynamic parameters in normal Sprague-Dawley rats. In: Faculty of Medical Sciences 25th Annual Research Conference and Workshop on One Health, One Caribbean. Kingston: Faculty of Medical Sciences, The University of the West Indies, Mona, Jamaica; 2016. p. 49.

    Google Scholar

  20. Peddie D, Bryan S, Alexander-Lindo R. Hypoglycaemic potential of Smilax balbisiana (Chainy Root) extracts in normal, healthy Sprague- Dawley rats. In: The University Diabetes Outreach Program 23rd International Conference, Diabetes and the Skin: Be Aware. St. Ann: Scientific Research Council, Jamaica; 2017. p. 34.

    Google Scholar

  21. Wilson RD, Islam MS. Fructose-fed streptozotocin-injected rat: an alternative model for type 2 diabetes. Pharmacol Rep. 2012;64(1):129–39.

    Article  CAS  PubMed  Google Scholar

  22. Sai V, Chaturvedula P, Prakash I. Isolation of stigmasterol and β-sitosterol from the dichloromethane extract of Rubus suavissimus. Int Curr Pharm J. 2012;1(9):239–42.

    Article  Google Scholar

  23. Picking D, Younger N, Mitchell S, Delgoda R. The prevalence of herbal medicine home use and concomitant use with pharmaceutical medicines in Jamaica. J Ethnopharmacol. 2011;137(1):305–11.

    Article  PubMed  Google Scholar

  24. Seo HK, Lee JH, Kim HS, Lee CK, Lee SC. Antioxidant and antimicrobial activities of Smilax China L. leaf extracts. Food Sci Biotechnol. 2012;21(6):1723–7.

    Article  Google Scholar

  25. Peddie DA, Bowen-Forbes CS, Alexander-Lindo RL. The ethnopharmacological effects of crude extracts from Smilax balbisiana (Chainy root) rhizomes. Med Aromat Plants. 2020;9(6):1–6.

    Google Scholar

  26. Romo-Pérez A, Escandón-Rivera SM, Andrade-Cetto A. Chronic hypoglycemic effect and phytochemical composition of Smilax moranensis roots. Rev Bras. 2019;29(2):246–53.

    Google Scholar

  27. Pérez-Nájera VC, Gutiérrez-Uribe JA, Antunes-Ricardo M, Hidalgo-Figueroa S, Del-Toro-Sánchez CL, Salazar-Olivo LA, et al. Smilax aristolochiifolia root extract and its compounds chlorogenic acid and astilbin inhibit the activity of α-amylase and α-glucosidase enzymes. Evid Based Complement Alternat Med. 2018;2018:1–12.

    Article  Google Scholar

  28. Kim YM, Jeong YK, Wang MH, Lee WY, Rhee HI. Inhibitory effect of pine extract on α-glucosidase activity and postprandial hyperglycemia. Nutrition. 2005;21(6):756–61.

    Article  CAS  PubMed  Google Scholar

  29. Su CH, Lai MN, Ng LT. Inhibitory effects of medicinal mushrooms on α-amylase and α-glucosidase – enzymes related to hyperglycemia. Food Funct. 2013;4(4):644–9.

    Article  CAS  PubMed  Google Scholar

  30. Taylor L. Technical data report for sarsaparilla Smilax officinalis. Austin: Sage Press Inc; 2003.

    Google Scholar

  31. Ullah H, Khan H. Epigenetic drug development for autoimmune and inflammatory diseases. In: Histone Modifications in Therapy: Academic Press; 2020. p. 395–413.

  32. Saeidnia S, Azadeh M, Ahmad G, Mohammed A. The story of beta-sitosterol-a review. European J Med Plants. 2014;4(5):590–609.

    Article  CAS  Google Scholar

  33. Jamaluddin F, Mohamed S, Lajis MN. Hypoglycaemic effect of Parkia speciosa seeds due to the synergistic action of β-sitosterol and stigmasterol. Food Chem. 1994;49(4):339–45.

    Article  CAS  Google Scholar

  34. Ramu R, Shirahatti PS, Nayakavadi S. R V, Zameer F, Dhananjaya BL, et al. the effect of a plant extract enriched in stigmasterol and β-sitosterol on glycaemic status and glucose metabolism in alloxan-induced diabetic rats. Food Funct. 2016;7(9):3999–4011.

    Article  CAS  PubMed  Google Scholar

  35. Borse SP, Singh DP, Upadhyay D, Nivsarkar M. Potential synergistic effects of quercetin with other phytoconstituents of Costus pictus (insulin plant) extract in the control of hyperglycemia and prevention of NSAID-induced gastroenteropathy in diabetic rats. Food Chem Toxicol. 2018;120:448–61.

    Article  CAS  PubMed  Google Scholar

  36. Mendes MF, David I, Bogle L. Evaluation of the effects and mechanisms of bioactive components present in hypoglycemic plants. Int J Chem Biomol Sci. 2015;1(3):167–78.

    CAS  Google Scholar

  37. Delgado-Pelayo R, Hornero-Méndez D. Identification and quantitative analysis of carotenoids and their esters from sarsaparilla (Smilax aspera L.) berries. J Agric Food Chem. 2012;60(33):8225–32.

    Article  CAS  PubMed  Google Scholar

  38. Calder PC. Functional roles of fatty acids and their effects on human health. J Parenter Enter Nutr. 2015;39(1 Suppl):18S–32S.

    Article  Google Scholar

  39. Moghadasian MH, Shahidi F. Fatty acids. In: International Encyclopedia of Public Health. 2nd ed: Elsevier; 2017. p. 114–22.

  40. Fujiwara K, Maekawa F, Yada T. Oleic acid interacts with GPR40 to induce ca 2+ signaling in rat islet β-cells: mediation by PLC and L-type ca 2+ channel and link to insulin release. Am J Physiol Metab. 2005;289(4):E670–7.

  41. Itoh Y, Kawamata Y, Harada M, Kobayashi M, Fujii R, Fukusumi S, et al. Free fatty acids regulate insulin secretion from pancreatic β cells through GPR40. Nature. 2003;422(6928):173–6.

    Article  CAS  PubMed  Google Scholar

  42. Campillo JE, Luyckx AS, Torres MD, Lefebvre PJ. Effect of oleic acid on insulin secretion by the isolated perfused rat pancreas. Diabetologia. 1979;16(4):267–73.

    Article  CAS  PubMed  Google Scholar

  43. Daley-Beckford DK. The isolation, purification and elucidation of the hypoglycaemic principles of Eucalyptus camaldulensis Dehnh. In: (Myrtaceae) and their hypotensive effect in normoglycaemic Sprague-Dawley rats: The University of the West Indies, Mona, Jamaica; 2013.

  44. Orhan N, Aslan M, Demirci B, Ergun F. A bioactivity guided study on the antidiabetic activity of Juniperus oxycedrus subsp. oxycedrus L. leaves. J Ethnopharmacol. 2012;140(2):409–15.

  45. Pu J, Peng G, Li L, Na H, Liu Y, Liu P. Palmitic acid acutely stimulates glucose uptake via activation of Akt and ERK1/2 in skeletal muscle cells. J Lipid Res. 2011;52(7):1319–27.

  46. Kadan S, Saad B, Sasson Y, Zaid H. In vitro evaluation of anti-diabetic activity and cytotoxicity of chemically analysed Ocimum basilicum extracts. Food Chem. 2016;196:1066–74.

    Article  CAS  PubMed  Google Scholar

  47. Benzler M, Benzler J, Stoehr S, Hempp C, Rizwan MZ, Heyward P, et al. “Insulin-like” effects of palmitate compromise insulin signalling in hypothalamic neurons. J Comp Physiol B. 2019;189(3):413–24.

    Article  CAS  PubMed  Google Scholar
